Check Valves

Check Valves (Medium & HP Series) For Pressure up to 10,000 psi (690 bar)

PANAM Check Valves (Medium & High Pressure Series) are designed to provide high-pressure check valves capable of handling pressures up to 10,000 psi (690 bar). These valves are constructed from 316 stainless steel and are available in various designs, including ball-seal poppet, soft-seal poppet, and dual-seal ball configurations.

Features

  • Working Pressure: Up to 10,000 psi (690 bar)
  • Connection Sizes: Available in 1/4", 3/8", 1/2", 9/16", 3/4", and 1"
  • Connection Types: Medium and high-pressure cone and thread, NPT, BSPT, and BSPP threaded connections
  • Cracking Pressure : Nominal Cracking Pressure 15 psi (1.0 bar)
  • Temperature Range: Up to 650°F (343°C)
  • Compliance: Check valves can be supplied to meet the latest NACE MR0175 and NACE MR0103 (Sour Gas Service) standards
