Custom Manifolds
Custom Manifolds (Medium & HP Series) For Pressure up to 60,000 psi (4134 bar)
PANAM Custom Manifold (Medium & High Pressure Series) are designed to optimize fluid system performance in high-pressure applications, with pressure rating up to 60000 psi (4134 bar). These manifolds are engineered to meet the unique demands of your system. With a focus on performance, reliability, and convenience, our custom manifolds integrate a variety of valve configurations including needle valves, ball valves, and check valves ensuring seamless operation for even the most complex setups.




Features
- Working Pressure: Up to 60,000 psi (4134 bar)
- Connection Sizes: Available in 1/4", 3/8", 1/2", 9/16", 3/4", and 1"
- Connection Types: Medium and high-pressure cone and thread, NPT
- High-Quality Materials: High tensile strength stainless steel, as well as exotic materials such as Hastelloy C, Inconel 625, Duplex, and Super Duplex.
- Design Flexibility: Each manifold is built to your exact specifications, optimizing space, reducing leak points, and enhancing system efficiency.
- Single Block Construction: Machined from a single solid block with multiple outlet connections, our custom manifolds eliminate potential leak paths, improving safety and reducing maintenance.
-
Versatile Configurations: Whether you need compact, lightweight designs or robust, multi-valve arrangements, PANAM’s expert engineering team tailors each manifold to match your requirements.
- Compliance: Relief valves can be supplied to meet the latest NACE MR0175 and NACE MR0103 (Sour Gas Service) standards
