H2 Custom Manifolds
PANAM Custom Manifolds (Medium & High Pressure Series) are designed entirely based on customer specifications, providing tailor-made solutions for fluid and gas distribution in high-pressure applications. Whether you need specific valve configurations, unique port layouts, or specialized materials, PANAM ensures that each manifold is precisely engineered to optimize performance, minimize leak paths, and enhance system safety.
Our custom manifolds support pressures up to 60,000 psi (4134 bar) and can be configured to seamlessly integrate with your existing system, making them ideal for industries such as hydrogen applications, oil & gas, aerospace, chemical processing, and industrial automation.
Features & Benefits
- Working Pressure: Up to 60,000 psi (4134 bar)
- Connection Sizes: Available in 1/4", 3/8", 1/2", 9/16", 3/4", and 1"
- Connection Types: Medium and high-pressure cone and thread, NPT
- High-Quality Materials: High tensile strength stainless steel, as well as exotic materials such as Hastelloy C, Inconel 625, Duplex, and Super Duplex.
- Design Flexibility: Each manifold is built to your exact specifications, optimizing space, reducing leak points, and enhancing system efficiency.
- Single Block Construction: Machined from a single solid block with multiple outlet connections, our custom manifolds eliminate potential leak paths, improving safety and reducing maintenance.
- Versatile Configurations: Whether you need compact, lightweight designs or robust, multi-valve arrangements, PANAM’s expert engineering team tailors each manifold to match your requirements.
- Compliance: Relief valves can be supplied to meet the latest NACE MR0175 and NACE MR0103 (Sour Gas Service) standards.
Applications
- Hydrogen Refueling Stations
- Hydrogen Storage & Transportation Systems
- Fuel Cell Technology
- Aerospace & Automotive Hydrogen Applications
- Cryogenic & High-Pressure Hydrogen Research
- Hydrogen-Based Industrial Processes
