Gauge Root Valves

Gauge Root Valves For Pressure up to 10,000 psi (689 bar)

PANAM  Gauge Root Valves are used for safe installation in pressure switches, gauges and differential pressure transmitters, suitable for Block and Bleed assemblies to test pressure source required in sampling line or purge valve.




Features

  • Working Pressure: Up to 10,000 psi (689 bar)
  • Gauge Root Valves are available in SS 316, Duplex, Monel & Hastelloy Materials.
  • Size ranging from 1/2″ to 3/4”.
  • PTFE standard gland packing, Alternate graph oil packing for high temperature.
    temperature upto 538°C (1000°F).
  • Non-Rotating Vee-tip / ball tip provides repetitive & leak tight shut-off.
  • Available in soft seat.
  • NACE certification available upon request.
  • Heat code traceability.




  Download Catalogue    Send Enquiry

Products

Male x Female Threaded, 6000 psi                 Male x Female Threaded,                               Male x Female Threaded,                    PGMale x Female Threaded,                                                                                                                                                             Soft Seat, 6000 psi                                           6000 psi, Long body                         Soft Seat, 6000 psi, Long Body

​
