Needle Valve IB Series Size 1/4" NPT Female Angular Configuration CV 0.73 Orifice 6.4 mm

• Body Material- 316 Stainless Steel
• Series - IB Series
• Port Size - 1/4 in.
• End Connection - NPT Female
• Configuration - Angular
• Cv - 0.73
• Orifice - 6.4 mm

IB Series Needle Valves

Features

• PANAM IB (Integral Bonnet) Needle Valves.
• IB Needle Valves are available in SS 316, Duplex, Monel & Hastelloy Materials in forged & bar stock construction.
• Variety of end connections – Male & Female NPT, BSPP, BSPT, ISO tapered pipe ends & PANAM tube fittings.
• Maximum working pressure up to 6,000 psig. (414 bar).
• Size ranging from 1/8″ to 1/2”.
• PTFE standard gland packing, Alternate Graphoil packing for high temperature. Max. temperature up to 538°C (1000°F).
• Non-Rotating Vee-tip / Ball tip provides repetitive & leak tight shut-off.
• NACE certification available upon request.
• Heat code traceability.
