Needle Valve IB Series Size M20x1.5 Metric Thread Straight Configuration CV 1.8 Orifice 9.5 mm

https://www.panamvalves.co.uk/web/image/product.template/2498/image_1920?unique=71d41eb
Specifications
  • Body Material- 316 Stainless Steel
  • Series - IB Series
  • Thread - M20x1.5
  • End Connection - Metric Thread
  • Configuration - Straight
  • Cv - 1.8
  • Orifice - 9.5 mm

IB Series Needle Valves

Features
  • PANAM IB (Integral Bonnet) Needle Valves.
  • IB Needle Valves are available in SS 316, Duplex, Monel & Hastelloy Materials in forged & bar stock construction.
  • Variety of end connections – Male & Female NPT, BSPP, BSPT, ISO tapered pipe ends & PANAM tube fittings.
  • Maximum working pressure up to 6,000 psig. (414 bar).
  • Size ranging from 1/8″ to 1/2”.
  • PTFE standard gland packing, Alternate Graphoil packing for high temperature. Max. temperature up to 538°C (1000°F).
  • Non-Rotating Vee-tip / Ball tip provides repetitive & leak tight shut-off.
  • NACE certification available upon request.
  • Heat code traceability.
£ 40.00 £ 40.00

Not Available For Sale

This combination does not exist.

Metric Thread M20x1.5
